HDMI Audio Embedder with built-in Repeater (4K, HDCP2.2, HDMI2.0)

The AU-11CA-4K Audio Embedder lets you insert an external audio signal into any HDMI source. The device allows you to insert analogue or digital stereo and multi-channel digital surround sound signals (via Optical) to give users the capability to overcome audio issues within complex HDMI installation. The AU-11CA-4K also repeats the HDMI signal to allow an
extended total HDMI cable range. This device supports 4K resolutions enabling flexible audio signal management into ultra high definition video signal paths.

• Compliant with HDMI, HDCP 1.2 and DVI 1.0
• Supports HDMI and Optical S/PDIF audio sample rate up to 192 kHz
• Supports LPCM Stereo, DTS and Dolby Digital via Optical input
• HDMI signal amplification and equalisation supporting HDMI cable distance of 10m either side of the device at full 1080p.
• Supports resolutions VGA~WUXGA, 480i~1080p, 4K UHD@24/25/30Hz (RGB 4:4:4 & YUV 4:2:2), 4K UHD@ 60Hz (YUV 4:2:0), 4K/2K@24/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and 4K/2K@ 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings
• Supports 3D signal
